Engine Type: 686 cc liquid-cooled, SOHC 4-stroke; 4-valves

Bore x Stroke: 102.0 mm × 84.0 mm

Compression Ratio: 10.0:1

Fuel Delivery: Yamaha Fuel Injection (YFI) with 44 mm throttle body

Ignition: TCI (Transistor Controlled Ignition)

Starting System: Push-button electric

Transmission: 5-speed with reverse; wet multiplate heavy-duty clutch

Drivetrain: 2WD; X-ring chain

Suspension & Brakes

• Front Suspension: Independent double wishbone with fully adjustable (high/low-speed compression, rebound, threaded preload) piggyback shocks; 9.1 inches of travel
• Rear Suspension: Cast aluminum swingarm with fully adjustable piggyback shocks; 10.1 inches of travel
• Front Brakes: Dual hydraulic discs
• Rear Brakes: Hydraulic disc
•

•

• Tires, Wheels & Dimensions
  • Front Tires: Maxxis AT22 × 7-10
  • Rear Tires: Maxxis AT20 × 10-9
  • Overall Length: 72.6 inches
  • Overall Width: 45.5 inches
  • Overall Height: 43.9 inches
  • Wheelbase: 50.4 inches
  • Seat Height: 32.7 inches
  • Ground Clearance: 9.5 inches (maximum) [1]
